HDD

• Processors:

  • Supports 1 or 2 Intel Xeon processors:

    • 2.8 GHz 2MB Level 2 Cache 800MHz front-side bus supporting Hyper-Threading Technology

    • 3.4 GHz 2MB Level 2 Cache 800MHz front-side bus supporting Hyper-Threading Technology

    • 3.6 GHz 2MB Level 2 Cache 800MHz front-side bus supporting Hyper-Threading Technology

    • Intel Chipset is E7520

• Memory:

  • 8 DIMM slots, supporting up 16GB DDR2-400MHz memory

  • 1 GB of PC2-3200 DDR2 SDRAM running at 400MHz with Advanced ECC capabilities standard, expandable to 16 GB

• Storage Controller:

  • Serial ATA (SATA) models offer SATA controller in the chipset

  • SCSI models will have SCSI controller in a slot (occupies low-profile slot)

• Internal Drive Support:

  • Support for up to two SATA/SCSI non-hot plug hard drives

  • Internal storage capacity of up to 1TB (2 x 500GB non-hot plug SATA HDDs), or 292GB (2x146GB NHP SCSI HDDs)

• Network Controller:

  • Two integrated Dual Broadcom 10/100/1000 5721 NICs (Wake on LAN and PXE capable)

  • Integrated 10/100 NIC dedicated for server management

• Expansion Slots:

  • Two PCI-X 64-bit/133MHz PCI slots operating at 3.3 volts (one full-length, one low-profile)

  • Includes one full-length, full-height and one low-profile, half-length 64-bit/133MHz PCI-X slot; Optional PCI Express x8 on full-length, full-height slot

• USB Ports:

  • Four USB ports (two rear, two front)

• Optical Drives:

  • Optional DVD or CD-ROM drive

• Power Supply:

  • 500W Power Supply (Non-Hot Plug, autoswitching)

• Form Factor:

  • Rack Mount (1U)

• Management:

  • ROM Setup Utility

  • HP ProLiant Lights Out 100i Remote Management support standard

  • IPMI 2.0 support

• Warranty:

  • Protected by HP Services, including a one-year, limited warranty, Parts only 1 year limited Global warranty - Certain restrictions and exclusions apply.


• Intelligent Networking Pack - detects and analyzes network bottlenecks or broken network linkages and steers traffic to the optimum route based on network conditions, plus it provides an extra layer of protection. The virus throttle feature of the solution slows the propagation of fast spreading virus.
• Vulnerability and Patch Management Pack - identifies and remediates software security vulnerabilities due to missing patches as well operating system configurations that can be exploited by viruses, worms, and other blended threats.

CAUTION: If a third-party rack is used, observe the following additional requirements to ensure adequate airflow and to prevent damage to the equipment:

Front and rear doors: If your 42U server rack includes closing front and rear doors, you must allow 5,350 sq cm (830 square inches) of hole evenly distributed from top to bottom to permit adequate airflow (equivalent to the required 64 percent open area for ventilation).
Side: The clearance between the installed rack component and the side panels of the rack must be a minimum of 7 cm (2.75 inches)
CAUTION: Always use blanking panels to fill all remaining empty front panel U-spaces in the rack. This arrangement ensures proper airflow. Using a rack without blanking panels results in improper cooling that can lead to thermal damage.

NOTE: For additional information, refer to the Setup and Installation Guide or the Documentation CD provided with the server, or to the server documentation located in the Support section at the following URL: http://h18000.www1.hp.com/products/servers/proliantdl140/index.html

HP Factory Express offers configuration, customization, integration and deployment services for HP servers and storage products. Customers can choose how their factory solutions are built, tested, integrated, shipped and deployed.

Factory Express offers service packages for simple configuration, racking, installation, complex configuration and design services as well as individual factory services, such as image loading, asset tagging, and custom packaging. HP products supported through Factory Express include a wide array of servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades, HP BladeSystem, HP 9000 servers as well as the MSA1000, VA7xxx, EVA, XP, rackable tape libraries and configurable network switches.

For more information on Factory Express services for your specific server model please contact your sales representative or go to http://www.hp.com/go/factory-express.

This product is covered by a global limited warranty and supported by HP Services and a worldwide network of resellers and service providers. Hardware diagnostic support and repair is available for three years from date of purchase. Support for software and initial setup is available for 90 days from date of purchase. Additional support may be covered under the warranty or available for an additional fee. Enhancements to warranty services are available through HP Care Pack services or customized service agreements.

NOTE: Server Warranty includes 1 year Parts only. Additional information regarding worldwide limited warranty and technical support is available at: http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html

HP Care Pack services include coverage for the HP branded hardware options qualified for the server, purchased at the same time or afterward, internal to the enclosure, as well as 22" and smaller external monitors and tower UPS options up to 3kVA; these items will be covered at the same service level and for the same coverage period as the server. Coverage of UPS Battery is not included, standard warranty terms & conditions apply. For servers or storage systems installed within a rack, service also covers all HP qualified rack options installed within the same rack.

HP services provide continuous care and support expertise with committed response designed to meet your IT and business needs.

To fully capitalizing on your HP ProLiant servers' capabilities requires a service partner who thoroughly understands your server technology and systems environment. HP Services, an industry leader in provision of multi vender support solutions provides a range of support services designed to meet the varying needs of business. Whether an SMB or large global corporation HP has a ProLiant server support offer to help you speedily deploy and maximize system uptime.

Enhanced Care - Minimum recommended service support offer designed to ensure customers have access to expert assistance, whenever they need it.

• Next Business Day on site coverage, 3 Years



Continuance Care - Recommended service, delivering cost-effective support options designed to extend HP Services committed response and guaranteed fix times, designed to speed problem identification and resolution.

• 4-Hour On-site Service, 5-Day x 13-Hour Coverage, 3 Years



Total Care - Highest HP Support service level recommend to help increase IT performance and availability with comprehensive, integrated hardware and software services

• 4-Hour On-site Service, 7-Day x 24-Hour Coverage, 3 Years



Deployment Services - HP Installation and Start Up services designed to take time, risk, and worry out of the deployment of ProLiant servers - and free customers IT support staff to focus on what they do best, their business.

• Installation of a ProLiant server as per Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl. HP holidays

For a complete listing of service offerings and information visit:
http://www.hp.com/services/proliantservices
http://www.hp.com/go/proliant/carepack

365403-B21

Following are memory options available from HP:

4096 MB of Advanced ECC PC2-3200 DDR SDRAM DIMM Memory Kit (2 x 2048 MB)

 343057-B21

2048 MB of Advanced ECC PC2-3200 DDR SDRAM DIMM Memory Kit (2 x 1024 MB)

 343056-B21

Relative Humidity
(non-condensing)

L WAd (BELS)

L WAd (BELS)
