Intel Pentium
4 Processors with HT Technology and EM64T 3.4 GHz with 1M or 2M L2 Cache
Intel
Pentium 4 Processors with HT Technology and EM64T 3.6 GHz with 1MB or 2MB Level
2 Cache (Factory Integrated Only)
Up to 4GB
of advanced ECC PC3200 DDR 400MHz SDRAM Memory
1 GB standard in all Pentium 4 models
512 MB in Celeron D
models
Two available PCI-X slots, including one
full-length 64-bit/133MHz slot and one half-length, low-profile 64-bit/100MHz
slot
Optional PCI-Express full-length slot
Embedded
NC7782 Dual Port PCI-X 10/100/1000T Gigabit network adapter
Integrated
iLO Remote Management
HP embedded 2 Port SATA Controller
with RAID 0/1 support
1U (1.75") Form Factor
Optional
CD,DVD, or CD-RW/DVD Combo drive and Floppy drive
Four USB
ports (1 front, 1 internal and 2 in rear)
Intel E7221 Chipset
with 800MHz Front Side Bus (533MHz for Celeron Processors)
New
spring-loaded Universal sliding rails for in rack servicing ship standard
Automatic
Server Recovery (ASR), ROM Based Setup Utility (RBSU), HP System Insight Manager,
Status LEDs including system health and UID and SmartStart
Internal
Storage capacity of 1TB (2 x 500GB SATA) or 144GB (2 x 72GB U320 or SAS)
350
Watt PFC Power Supply
Internal USB port can also be used
as internal USB port for leave-in USB key support
Protected
by HP Services and a worldwide network of resellers and service providers. Three-year
Next Business Day, on-site limited global warranty. Certain restrictions and exclusions
apply. Pre-Failure Notification on processors, memory, and SCSI hard drives. SATA
hard drives have a one-year warranty.
Intel Pentium 4
with HT Technology and EM64T 3.4 GHz
Intel Pentium 4
with HT Technology and EM64T 3.6 GHz (Factory Integrated Only)
Processor Cache
One of the following depending on Model
256KB Level 2 Cache
(Celeron D models)
1MB Level 2 Cache
(Pentium 4 models)
2MB Level 2 Cache
(Pentium 4 models)
Chipset One of the following depending on Model
Intel E7221 chipset
with 800MHz Front Side Bus (Pentium 4 Models)
Intel E7221 chipset
with 533MHz Front Side Bus (Celeron D Models)
Memory Protection
Advanced ECC
Memory One
of the following depending on Model
Type
PC3200 DDR SDRAM running at
400MHz
Standard
(Pentium 4 models)
1 GB (1x 1024 MB)
Standard
(Celeron D models)
512 MB (1 x 512 MB)
Maximum
4 GB
Network Controller
Embedded NC7782
Dual Port PCI-X 10/100/1000T Gigabit network adapter
Expansion Slots
Slot Number
Bus Speed
Height
Hot Plug
PCI Voltage
PCI-X Non Hot-Plug
Riser
1
64-bit/133 MHz PCI-X
Full
no
3.3 Volt
2
64-bit/100 MHz PCI-X
Half
no
3.3 Volt
PCI-Express Non
Hot-Plug Riser (Optional)
1
PCI Express x4
(x8 connector)
Full
no
N/A
2
64-bit/100 MHz PCI-X
Half
no
3.3 Volt
Storage Controllers
HP embedded 2 Port
SATA Controller with RAID 0/1 support. SAS and SCSI controllers available
via PCI card.
Storage
Diskette Drive
Optional
1.44 MB Diskette Drive option kit is available NOTE: Purchase of floppy drive is
required to implement embedded SATA RAID 0/1 with SmartStart 7.2.
Optical Drive
Optional
CD-ROM, DVD-ROM option kits available NOTE: Purchase of CD-ROM is required
for installation of SmartStart.
Integrated ATI RAGE XL Video
Controller with 8-MB SDRAM Video Memory
Form Factor
Rack (1U), (1.70 in/4.45 cm)
ProLiant Essentials
Foundation Pack Software
HP
Systems Insight Manager
HP's
new HP Systems Insight Manager (HP SIM) helps maximize system uptime and performance
and reduce system maintenance costs by providing proactive notification of problems
before those problems result in unplanned downtime or reduced productivity. HP
SIM are both easy to set up work with the Insight Management Agents, integrated
Lights-Out and Version Control Agents to deliver robust fault, configuration,
and asset management as well as remote administration. With HP SIM customers will
also be able to take advantage of role-based security; the ability to manage ProLiant,
Integrity, and HP 9000 systems; and plug-ins for storage, client, printer, and
power management as well as server rapid deployment, performance management, and
workload management. For more details on HP SIM visit http://www.hp.com/go/hpsim.
SmartStart
SmartStart
is a tool that simplifies server setup, providing a rapid way to deploy reliable
and consistent server configurations. For more information, please visit the SmartStart
Web site at http://www.hp.com/servers/smartstart. SmartStart version supported (minimum): SmartStart
7.2.
Insight
Management Agents
The
Insight
Management Agents form the foundation for HP's Intelligent Manageability strategy.
They provide direct, browser-based access to in-depth instrumentation built into
HP servers, workstations, desktops, and portables, and send alerts to HP Systems
Insight Manager and other enterprise management applications in case of subsystem
or environmental failures. For additional information about the Management Agents
and other management products from HP, please visit the management Web site at
http://www.hp.com/servers/manage.
Subscriber's Choice
Subscriber's
Choice Driver and Support Alerts/Notifications is a web-based email subscription
service that provides automatic delivery of software and driver change notifications
for ProLiant products. Sign up at http://www.hp.com/go/subscriberschoice
and customize your profile to receive various new alerts as they become available,
on a weekly or monthly basis.
ROMPaq,
support software, and configuration utilities
The
latest software, drivers, and firmware fully optimized and tested for your ProLiant
server and options available in SmartStart or downloadable from Software and Drivers
download pages, linked from the SmartStart website at http://www.hp.com/servers/smartstart.
Survey Utility and diagnostics
utilities
The most advanced
configuration analysis, reporting and troubleshooting utilities used by HP and
at your fingertips, available in SmartStart.
Optional
ProLiant Essentials Value Packs
Optional software offerings that selectively extend the functionality of an
Adaptive Infrastructure to address specific business problems and needs:
Rapid Deployment Pack (RDP) is an automated deployment and
provisioning solution for all ProLiant servers. RDP includes the
ProLiant Integration Module featuring ProLiant server pre-configured
events for OS installation, and optimized software drivers, firmware
and management agents. Every RDP disc includes 10-node trial licenses
for evaluation purposes. RDP requires a license for each server
deployed and is available for purchase with HP servers. For more
information, visit: http://www.hp.com/servers/rdp.
Workload Management Pack - provides easier management of complex
environments, improving overall server utilization and enabling
Windows® 2000 customers for the first time to confidently deploy
multiple applications on a single multiprocessor ProLiant Server.
Integrated Lights-Out Advanced Pack - upgrades the Integrated
Lights-Out processor to full virtual presence and control with
graphical console and virtual media.
Performance Management Pack - a performance management solution
that identifies and explains hardware performance bottlenecks
on ProLiant servers and attached options enabling users to better
utilize their valuable resources.
Intelligent Networking Pack - detects and analyzes network bottlenecks
or broken network linkages and steers traffic to the optimum route
based on network conditions, plus it provides an extra layer of
protection. The virus throttle feature of the solution slows the
propagation of fast spreading virus
Vulnerability and Patch Management Pack - identifies and remediates
software security vulnerabilities due to missing patches as well
operating system configurations that can be exploited by viruses,
worms, and other blended threats
Virtual Machine Management Pack - provides central management
and control of virtual machines from Microsoft and VMware. Integrated
approach provides the ability to manage both physical and virtual
resources from a single management console.
Server Migration Pack - The Server Migration Pack automates
the manual processes required for migrating servers between physical
or virtual platforms (P2V, V2P, and V2V).
NOTE:
Flexible and volume quantity license kits are available for ProLiant Essentials
Value Packs. Refer to http://www.hp.com/servers/proliantessentials
or the various ProLiant Essentials Value Pack product QuickSpecs for more information.
NOTE: For more information regarding ProLiant Essentials Software,
please see the following URL: http://www.hp.com/servers/proliantessentials
Industry Standard
Compliance
ACPI 2.0
PCI 2.2 Compliant
PXE Support
WOL Support
Microsoft® Logo certifications
USB 2.0
Intelligent
Manageability
Automatic Server Recovery (ASR)
iLO Advanced Pack (optional)
HP Systems Insight Manager
Integrated Management Log
Drive Parameter Tracking (with Smart Array Controllers)
Dynamic Sector Repairing (with Smart Array Controllers)
Pre-Failure Warranty (covers processors, SCSI hard drives and memory)
Security
Power-on password
Keyboard password
Diskette drive control
Diskette boot control
Removable CD-ROM/Diskette Drive Assembly
Administrator's password
Server Power Cords
North America
One 12' Lowline and one 10'
Highline (IEC-IEC) power cord ships standard
Japan
One 10' IEC (Highline) and one
12' Lowline power cord ships standard
ROW
One 10' Highline (IEC) power
cord ships standard
Localized cables included with
geographic specific models in other world regions.
Power Supply
Auto-sensing 350-Watt PFC Power
Supply, CE Mark Compliant
Microsoft Windows 2000 Server
Windows Server 2003 (web and standard editions; standard edition for 64-bit
extensions)
Linux (Red Hat, SuSE, UnitedLinux)
VMware Virtualization Software
Rack 10000 series Cabinets
The increasing power of new high-performance processor technology requires
increased cooling efficiency for rack-mounted servers. The 10000 Series
Racks provide enhanced airflow for maximum cooling, allowing these racks
to be fully loaded with servers using the latest processors.
CAUTION: If a third-party rack is used, observe the following additional
requirements to ensure adequate airflow and to prevent damage to the equipment:
Front and rear doors: If your 42U server rack includes closing front
and rear doors, you must allow 5,350 sq cm (830 square inches) of hole evenly
distributed from top to bottom to permit adequate airflow (equivalent to the required
64 percent open area for ventilation).
Side: The clearance between
the installed rack component and the side panels of the rack must be a minimum
of 7 cm (2.75 inches)
CAUTION: Always use blanking panels to
fill all remaining empty front panel U-spaces in the rack. This arrangement ensures
proper airflow. Using a rack without blanking panels results in improper cooling
that can lead to thermal damage.
NOTE: For additional information, refer to the Setup and Installation
Guide or the Documentation CD provided with the server, or to the server
documentation located in the Support section at the following URL: http://h18004.www1.hp.com/products/servers/proliantdl320/index.html.
HP Factory Express Capabilities
HP Factory Express offers configuration, customization, integration and
deployment services for HP servers and storage products. Customers can
choose how their factory solutions are built, tested, integrated, shipped
and deployed.
Factory Express offers service packages for simple configuration, racking,
installation, complex configuration and design services as well as individual
factory services, such as image loading, asset tagging, and custom packaging.
HP products supported through Factory Express include a wide array of
servers and storage: HP Integrity, HP ProLiant, HP ProLiant Server Blades,
HP BladeSystem, HP 9000 servers as well as the MSA1000, VA7xxx, EVA, XP,
rackable tape libraries and configurable network switches.
For more information on Factory Express services for your specific server
model please contact your sales representative or go to http://www.hp.com/go/factory-express.
This product is covered by a global limited warranty and supported by
HP Services and a worldwide network of resellers and service providers.
Hardware diagnostic support and repair is available for three years from
date of purchase. Support for software and initial setup is available
for 90 days from date of purchase. Additional support may be covered under
the warranty or available for an additional fee. Enhancements to warranty
services are available through HP Care Pack services or customized service
agreements.
NOTE: Limited warranty includes
3 year parts, 1 year labor, 1-year on-site support. NOTE: SATA drives have a 1 year warranty.
Care Pack services provide a range of life cycle support options that
let you choose the service levels that meet your business requirements,
from basic to mission-critical.
A full range of HP Care Pack hardware and software services are available
including:
Installation and start up
Education courses
Extended onsite hardware coverage hours from same business day 13
hours, 5 day to 24 hours, 7 days call window with options including
4-hour response or 6-hour Call To Repair
Comprehensive range of software technical support for Microsoft, Linux,
ProLiant Essentials and VMWare-based IT solutions helping to deliver
high level of application availability. Response times range from 30
mins for critical problems to 2 hours.
System Management, Performance Services and Mission Critical Support
Solution
HP Care Pack services include coverage for the HP branded hardware options
qualified for the server, purchased at the same time or afterward, internal
to the enclosure, as well as 22" and smaller external monitors and
tower UPS options up to 3kVA; these items will be covered at the same
service level and for the same coverage period as the server. Coverage
of UPS Battery is not included, standard warranty terms & conditions
apply. For servers or storage systems installed within a rack, service
also covers all HP qualified rack options installed within the same rack.
NOTE: For more
information on HP Care Pack services, contact any of our worldwide sales
offices or resellers or visit our worldwide Web site on the internet at:
http://www.hp.com/hps/carepack
NOTE: For more complete information on HP Services offerings, customers
and resellers, please visit us at: http://www.hp.com/hps
NOTE: Additional information regarding worldwide limited warranty and
technical support is available at: http://h18004.www1.hp.com/products/servers/platforms/warranty/index.html
Configuration Information - Factory Integrated Models (North America only)
NOTE:
For Configure to Order requirements within EMEA region, please consult local
Sales Contact. NOTE: HP does not allow factory integration of options
into standard models listed above. Configure-to-order servers must start
with a CTO Chassis. NOTE: This product offering does not support HP
Factory Express Server Configuration Level 1.
Step
1: Base Configuration (choose one of the following configurable models)
Models
HP ProLiant DL320G3
SATA Rack CTO Chassis (North America)
374295-405
Factory Integrated
Model ships with:
Embedded
NC7782 Dual Port PCI-X 10/100/1000T Gigabit network adapter
1 full length/height
and 1 half length-low profile 64bit PCI-X slot
Integrated Lights-Out
(iLO) embedded
DL320
G3 SAS/SATA HDD Backplane Option Kit
Rack (1U) form factor,
(1.75 in/4.45 cm)
HP ProLiant DL320G3
SCSI Rack CTO Chassis (North America)
383338-405
Factory Integrated
Model ships with:
Embedded
NC7782 Dual Port PCI-X 10/100/1000T Gigabit network adapter
1 full length/height
and 1 half length-low profile 64bit PCI-X slot
Non Hot Plug U320
SCSI Option Kit
Integrated
Lights-Out (iLO) embedded
DL320
G3 Non Hot Plug U320 SCSI Option Kit
Rack (1U) form factor,
(1.75 in/4.45 cm)
Step
2: Choose Required Options (only one of the following from each list unless
otherwise noted)
Processors
X3.6/PIV/2M DL320G3
FIO ALL
399664-B21
X3.4/PIV/2M DL320G3
FIO Base
385652-B21
X3.6/PIV/1M DL320G3
FIO Base
374868-B21
X3.4/PIV/1M DL320G3
FIO Base
374867-B21
X2.93/CELERON/256KB
DL320G3 FIO Base
374866-B21
Base
Memory
512 MB of Advanced
ECC PC3200 DDR SDRAM DIMM Memory Kit (1 x 512 MB)
HP
8 Internal Port SAS HBA with RAID NOTE:
The HP 8 Internal Port SAS/SATA HBA with RAID requires the purchase of the SATA
Rack FIO model and the DL320 SAS/SATA Hot Plug Cable option kit ( 398307-B21)
DL320 Hot Plug SAS/SATA
Cable Option Kit NOTE: This option
is required for the HP 8 int. Port SAS/SATA HBA with RAID. This option with the
addition of the DL320G3 SAS/SATA HDD Backplane Option Kit and the HP 8 int. Port
SAS/SATA HBA with RAID enables the DL320 G3 for Hot Plug and LED drive support.
DL320 G3 SAS/SATA
HDD Backplane Option Kit NOTE: This
option is required on the non-hard drive models for any supported SATA HDD options.
372704-B21
DL320 G3 Non Hot
Plug U320 SCSI Option Kit NOTE: This
option is required for use with any supported non Hot Plug U320 SCSI HDD options.
A PCI controller is also required; please see Storage Controllers below for U320
controller options.
ProLiant Essentials
Integrated Lights-Out Advanced Pack, 1 server Featuring:sophisticated virtual administration
features for ultimate control of servers in the data centers and remote
sites.
ProLiant Essentials
Intelligent Networking Pack, Single Server License NOTE: For use with a single server. Contains one license with a unique
license activation key and documentation.
ProLiant Essentials
Performance Management Pack, Single-Server License NOTE: For use with a single server.
Contains one license with a unique license activation key, HP Management
CD and documentation. NOTE: The most recent version of the software can always be downloaded
at http://www.hp.com/products/pmp.
ProLiant Essentials
Virtual Machine Management Pack, Single-Server License NOTE: For use with a single server.
Contains one license with a unique license activation key and documentation.
372214-B21
ProLiant
Essentials Server Migration Pack, Single-Migration License NOTE: Contains one license, enabling 1 server migration, with a unique
license activation key and documentation. NOTE: This license allows 1 server to be migrated from a physical
server to a virtual machine. Or this license can be used to migrate a virtual
machine from one virtualization layer i.e. VMware GSX to a different virtualization
layer such as VMware ESX or Microsoft Virtual Server 2005.
ProLiant Essentials
Vulnerability and Patch Management Pack
ProLiant Essentials
Vulnerability and Patch Management Pack, Single-Server License NOTE: For use with a single server.
Contains one license with a unique license activation key and documentation.
NOTE:
Flexible and volume quantity license kits are available for ProLiant
Essentials Value Packs. Refer to http://www.hp.com/servers/proliantessentials
or the various ProLiant Essentials Value Pack product QuickSpecs for more
information. NOTE: For more information regarding ProLiant Essentials Software,
please see the following URL: http://www.hp.com/servers/proliantessentials.
Memory (DIMMs)
1024 MB of Advanced ECC PC3200 DDR SDRAM DIMM Memory Kit (1 x 1024 MB)
DL320 G3 SAS/SATA HDD Backplane
Option Kit NOTE: When adding either SATA or
U320 SCSI drives to a non-hard drive DL320 G3 model, the appropriate option
kit above is required for operation.
NOTE: All U320
Universal Hard Drives are backward compatible to U2 or U3 speeds. U320 drives
require an optional U320 Smart Array Controller or U320 SCSI HBA to support U320
transfer rates. NOTE: Please see the Hard Drive QuickSpecs for Technical
Specifications such as capacity, height, width, interface, transfer rate, seek
time, physical configuration, and operating temperature: http://h18000.www1.hp.com/products/quickspecs/11531_div/11531_div.html
(Worldwide)
NOTE:
Please note that Serial ATA hot-plug capability and drive LEDs are not
supported by the DL320 G3 embedded SATA storage controller.The
purchase of the HP 8 Internal Port SAS HBA with RAID, the DL320 G3 SAS/SATA
HDD Backplane Option Kit, and the DL320 Hot Plug SAS/SATA Cable Option Kit
is required for Hot Plug and LED SAS/SATA support.
NOTE: SATA drives have a 1-year warranty. Please see the Hard Drive
QuickSpecs for Technical Specifications such as capacity, height, width,
interface, transfer rate, seek time, physical configuration, and operating
temperature: http://h18000.www1.hp.com/products/quickspecs/11940_div/11940_div.html
(Worldwide)
Storage Controllers
64-Bit/133-MHz
Single Channel Ultra320 SCSI HBA G2
HP
8 Internal Port SAS HBA with RAID NOTE:
The HP 8 int. Port SAS/SATA HBA with RAID requires the purchase of the SATA Rack
FIO model and the DL320 SAS/SATA Hot Plug Cable option kit ( 398307-B21).
NOTE: A minimum
of 1 GB of memory per port is required for NC370x adapters, with a maximum
of two NC370x ports permitted in a server. NOTE: Any NC61XX, NC71XX or NC77XX network adapter can be used for
redundancy with the embedded NC7782 network adapter.
HP StorageWorks Ultrium 232 Internal
Tape Drive (Carbonite) NOTE: No internal
tape drives fit inside this HP ProLiant server. The internal drive shown here
is for the 1U and 3U Rack-mount Kit.
HP
StorageWorks 1U Rack-Mount Kit NOTE: The 1U Rack-mount Kit can
support up to (2) half-height tape drives and compatible with multiple Single-Ended
and LVD SCSI tape drives including the DAT 24, DAT 40, DAT 72, DLT VS80, DLT VS160,
Ultrium 215, Ultrium 232 and Ultrium 448 tape drives.
NOTE: Required
to install the unit in a standard 19-inch rack; includes rails and rackmount instructions NOTE: Please reference the 1/8 Tape Autoloader QuickSpecs at http://www.hp.com/go/automation
for additional information needed to create a complete solution; reference current
compatibility information at http://www.hp.com/go/ebs
Tape
Libraries
HP StorageWorks MSL2024 Tape
Library
HP
StorageWorks MSL2024 1 Ultrium 960 Drive Library
NOTE:Please
reference the MSL2024, MSL4048 and MSL6000 Tape Library QuickSpecs athttp://www.hp.com/go/automation
for additional information needed to create a complete solution; reference current
compatibility information at http://www.hp.com/go/ebs
Magento-Optical Jukeboxes
HP StorageWorks 9.1 GB Entry-level
Optical Storage
NOTE: Please see
the StorageWorks Modular SAN Array 1500 cs QuickSpecs for additional options
and configuration information at: http://www.hp.com/go/MSA1500cs
StorageWorks Options
StorageWorks 2 Gb, 64-bit/133
MHz PCI-X-to-Fibre Channel Host Bus Adapter for Windows 2000, Windows Server
2003 and Linux NOTE: FCA2214 2 Gb Fibre Channel
Host Bus Adapter is a single channel, 64-bit/133 MHz PCI-X-to Fibre Channel
Host Bus Adapter (HBA) with an embedded multi-mode optical interface.
FCA2408 - HP StorageWorks 2 Gb,
64-Bit/133 MHz Single Channel, PCI- X-to-Fibre Channel Host Bus Adapter
for Windows® 2000 and Windows Server® 2003 NOTE: FCA2408 HP StorageWorks 2 Gb, 133 MHz
PCI-X-to-Fibre Channel Host Bus Adapter (HBA) with optical
small-form-factor (SFF) (LC) interface.
343073-B21
FCA2404DC - HP StorageWorks 2
Gb, Dual Channel, 133 MHz PCI-X-to-Fibre Channel Host Bus Adapter for Windows
2000, and Windows Server 2003 NOTE: FCA2404DC HP StorageWorks 2 Gb Fibre Channel
Host Bus Adapter is a dual channel, 133 MHz, PCI-X to Fibre Channel Host
Bus Adapter (HBA) with an embedded multi-mode optical interface.
323264-B21
FCA2404 - StorageWorks 2 Gb, single
channel, 133 MHz PCI-X-to-Fibre Channel Host Bus Adapter for Windows 2000,
Windows NT and Windows Server 2003 NOTE: FCA2404 StorageWorks 2 Gb, Fibre Channel
Host Bus Adapter is a single channel, multi-path failover, 133 MHz, PCI-X
to Fibre Channel Host Bus Adapter (HBA) with an embedded multi-mode
optical interface for Proliant Server connects.
305573-B21
StorageWorks 2 Gb, Dual Port,
64-Bit/133 MHz PCI-X-to-Fibre Channel Host Bus Adapter for W2K, Windows
Server 2003 and Linux NOTE: FCA2214DC StorageWorks 2 Gb
Dual Port, Fibre Channel Host Bus Adapter is a 64-bit/133 MHz, PCI-X-to
Fibre Channel Host Bus Adapter (HBA) with an embedded multi-mode optical
interface.
HP UPS R5500 XR, (6000VA, 5400
Watt), High Voltage (Int'l)
326529-B31
HP
UPS R12000 XR, N+ x (12KVA, 12KW) High Voltage (WW) NOTE: The UPS R12000 XR has a hardwired input and output connection.
207552-B22
USB
Options
USB Optical Scroll Mouse (Carbonite)
DD441B
USB 1.44-MB External Diskette
Drive (Carbonite)
DC141B
256MB HP Drive Key II (USB 2.0)
PH657A
ProLiant DL320 Deployment Options
Rack Adapter Kit NOTE: This kit allows HP rack servers
to fit in racks that are 24" wide.
332815-B21
NOTE: Telco Rack
Support - Support for all 2-post Telco racks requires the use of the standard
rack kit and an additional option kit from Rack Solutions: http://www.racksolutions.com/hp
NOTE:
xxxxxx-B21 (pallet) used to ship empty racks shipped on a truck. -B22 (shock pallet)
used to ship racks with equipment installed (by custom systems, VARs and Channels).
xxxxxx-B23 (crated) used for air shipments of empty racks.
NOTE:
Cat5e cables are required to connect Interface Adapters to Console Switches.
Cat5e cables can be found at the following URL: http://www.hp.com/go/kvm.
HP 1x 4 USB/PS2 KVM Switch, TT
(NA/JPN)
371301-D71
HP 1x 4 USB/PS2 KVM Switch, TT
(AU/NZ)
371301-011
HP 1x 4 USB/PS2 KVM Switch, TT
(UK)
371301-031
HP 1x 4 USB/PS2 KVM Switch, TT
(EU)
371301-A21
HP 1x 4 USB/PS2 KVM Switch, RM
(ALL)
371302-B21
HP PS2 KVM Cable with audio, 6',
2-pack
371730-B21
HP USB KVM Cable with audio, 6',
2-pack
371729-B21
NOTE:
For additional information regarding KVM switches, Serial Console servers,
rack mount monitors, keyboards and all related options please see the following
URL:http://www.hp.com/go/kvm.
NOTE: Cat5e cables
are required to connect Serial Adapters to Serial Console Servers. Additional
Serial Adapters and Cat5e cables can be found at the following URL: http://www.hp.com/go/kvm.
NOTE: For additional
information regarding KVM switches, Serial Console servers, rack mount monitors,
keyboards and all related options please see the following URL: http://www.hp.com/go/kvm.
Service and Support Offerings (HP Care Pack Services)
Hardware Services On-site
Service
Next Business Day On-site Service,
5-Day x 9-Hour Coverage, 3 Years, Electronic
U4479E
4-Hour On-site Service, 5-Day
x 13-Hour Coverage, 3 Years, Electronic
U4480E
4-Hour On-site Service, 7-Day
x 24-Hour Coverage, 3 Years, Electronic
U4481E
6-Hour Call to Repair, On-site
Service, 7-Day x 24-Hour Coverage, 3 Years, Electronic
U4482E
Installation & Start-up
Services
Hardware Installation, Electronic
U4490E
Installation & Start-Up of
a ProLiant server and Microsoft or Linux O/S per the Customer Description
and/or Data Sheet. To be delivered on a scheduled basis 8am-5pm, M-F, excl.
HP holidays, Electronic
U4491E
Support Plus
Onsite HW support, 8am-9pm, M-F,
4hr response and Microsoft O/S SW Tech support offsite, onsite at HP's discretion,
8am-9pm, M-F 2hr response time excl. HP holidays, Electronic
U4492E
Support Plus 24
Onsite HW support 24x7, 4hr response
and Microsoft O/S SW Tech support offsite, onsite at HP's discretion, 24x7
2hr response time incl. HP holidays, Electronic
U4493E
Onsite HW support 24x7, 4hr response
and SuSE Linux SW Tech support offsite, onsite at HP's discretion, 24x7
2hr response time incl. HP holidays, Electronic.
U6309E
Onsite HW support 24x7, 4hr response
and Red Hat ES Linux SW Tech support offsite, onsite at HP's discretion,
24x7 2hr response time incl. HP holidays, Electronic.
Standard Memory
512 MB PC3200 ECC DDR SDRAM installed (1 x 512 MB SDRAM DIMM) on Celeron
model; 1 GB (1 x 1024 MB SDRAM DIMMs) on all P4 models.
Standard Memory Plus Optional Memory
Up to 4096 MB memory is available with the optional installation of PC3200
ECC DDR SDRAM Memory kits.
NOTE:
The chart below represents the P4 models with 1GB standard memory, and does
not represent all possible configurations. Memory can be populated in any
order with any of the supported DIMMs listed. For optimal performance, the
total amount of memory in slots 1A and 2A should equal to the total amount
of memory in slots 3B and 4B.
Memory
Slot
1A
2A
3B
4B
Standard
1024 MB
1024 MB
Empty
Empty
Empty
Optional
2048 MB
512 MB
512 MB
512 MB
512 MB
Maximum
4096 MB
1024 MB
1024 MB
1024 MB
1024 MB
Following are memory options available from HP:
1024 MB of Advanced ECC PC3200 DDR SDRAM DIMM Memory Kit (1 x 1024
MB)
ATA data-transfer modes
supported
SATA 1.0, SATA II
PIO modes 0-4
Multiword DMA modes 0-2
Ultra DMA modes 0-6
RAID levels
0, 1
Feature
Supports Pre-Failure
Warranty of SATA Hard Drives
Support for Systems Insight Manager
Supports multiple logical volumes
Setup through ROM based Array Configuration Utility
Installation scripting support
OS Support
Microsoft Windows 2000
Server
Microsoft Windows Server 2003
Novell NetWare
Linux (Red Hat, SuSE, UnitedLinux)
NOTE: This controller
does not support LED functions
This controller does not support Hot Plug functions
US Site
DL Quickspecs
Search:
354560-B21
© 2012 Canada PartsDirect
